GD60110

Build

30x60cm / 60x60cm
Natural / Grip

Download catalogs

Sand

Taupe

Grey

Charcoal

Natural

Grip

30x60cm
11.8x23.6"

60x60cm
23.6x23.6"

All website photos are for reference only, , the accuracy and completeness information please refer with actual products.

Specifications Packing List

*Scroll left to right for the whole table

	30x60cm 11.8x23.6"		60x120cm 23.6x47.2"		60x60cm 23.6x23.6"
	30x60cm 11.8x23.6"	EN14411	60x120cm 23.6x47.2"	EN14411	60x60cm 23.6x23.6"	EN14411
Water Absorption(%)	≦0.1	≦0.5	≦0.1	≦0.5	≦0.1	≦0.5
Length	± 0.4	± 2.0	± 0.5	± 2.0	± 0.4	± 2.0
Width	± 0.4	± 1.8	± 0.5	± 2.0	± 0.4	± 2.0
Thickness	± 0.4	± 0.5	± 0.4	± 0.5	± 0.4	± 0.5
Straightness of Sides	± 0.4	± 1.5	± 0.4	± 1.5	± 0.4	± 1.5
Central Warpage	+0.6~-0.3	± 2.0	+0.6~-0.4	± 2.0	+0.6~-0.3	± 2.0
Edge Curvature	+0.5~-0.4	± 2.0	+0.5~-0.5	± 2.0	+0.5~-0.4	± 2.0
Warpage	± 0.8	± 2.0	± 1.0	± 2.0	± 1.0	± 2.0
Rectangularity	± 0.6	± 1.5	± 1.0	± 2.0	± 0.6	± 2.0
Breaking Strength Modulus of Rupture	S ≧ 2,000 N R ≧ 38 N/mm2	S ≧ 1,300 N R ≧ 35 N/mm2	S ≧ 2,600 N R ≧ 40 N/mm2	S ≧ 1,300 N R ≧ 35 N/mm2	S ≧ 2,200 N R ≧ 38 N/mm2	S ≧ 1,300 N R ≧ 35 N/mm2
Thermal Shock Resistance	Resistant	Test methond available	Resistant	Test methond available	Resistant	Test methond available
Resistance to Chemical	Minimum GLA	Minimum GB	Minimum GLA	Minimum GB	Minimum GLA	Minimum GB
Glazed Crack Resistance	Resistant	Resistant	Resistant	Resistant	Resistant	Resistant
Mahs hardness	-	-	-	-	-	-
Frost Resistance	Resistant	Resistant	Resistant	Resistant	Resistant	Resistant
Stains Resistance	Minimum class 5	Minimum class 3	Minimum class 5	Minimum class 3	Minimum class 5	Minimum class 3

*Scroll left to right for the whole table
